682 Series Positive Displacement Flow Meter

682 Series Positive Displacement Flow Meter – ±0.1% Accuracy

The 682 Series flow meter provides precise liquid measurement across a 250:1 turndown ratio, making it suitable for low-flow applications and varying delivery volumes. Its inline positive displacement design uses three reciprocating pistons, each measuring a defined volume of liquid.

A wobble plate coordinates the pistons and sliding valve, transferring smooth mechanical movement through the calibrator to the register. The self-lapping valve design supports sustained accuracy, with minimal measurement drift reported during a 54-million-litre service-life test.

Performance and specifications

Stated linear accuracy varies with the measuring range:

Meter versions and applications

• SP – Standard Petroleum: For compatible refined fuels, oils, antifreeze and vegetable oils.
• SPA – Aviation: For aviation gasoline, jet fuels and other compatible petroleum products.
• SPD – Ductile Iron: For compatible alternative fuels, including ethanol, methanol and biodiesel.
• AF – All Ferrous: For compatible industrial liquids, including fertilisers, solvents, paints, inks, adhesives and syrups.
• SS – Stainless Steel: For food processing and selected chemical applications, subject to material and seal compatibility.

Registration and accessories

Choose Veeder-Root mechanical registration or a TCS 3000 electronic register for delivery control and data handling. Available accessories include preset controls, ticket printers, pulse transmitters, air and vapour eliminators, and mechanical, pneumatic or electronic control valves.

The range offers configurations for international measurement and hazardous-area requirements. Select the meter materials, seals, registration and approvals to suit the liquid and installation.

ACCESSORIES

Mechanical Registration: Mechanical 5 wheel register V/R 7887 or 6 wheel register V/R 7886 with optional preset, ticket printer, swivel, micro switch and register mounted pulser.

Electronic Registration: TCS 3000 electronic register is a fully register is a fully integrated flow computer that will control all delivery operations. The modular design and open software architecture provide you with a tailored system that is expandable for future needs.

Pulse Transmission: The DMP pulse transmitters provide accurate signals for remote indiciation, totalizers and data monitoring systems by transferring the mechanical rotation of the flow meter into an electronic pulse.

Air/Vapor Elimination: Mechanical and electronic air eliminators are devices designed to extract free or accumulated volumes of air or vapor from a liquid dispensing system to achieve accurate measurement results.

Control Valves: Mechanical, pneumatic and electronic actuated piston and diaphragm control valves designed to meet the variety of needs in the fluids in the fluid process industry. Such valves include preset flow control valves, air differential control valves, pressure relief and safety valves.
