Z2000 ATEX Tank Gauge – Accuracy ±1%

An ATEX certified electronic tank gauge for petrol and other flammable fuels, giving a continuous litres and percentage readout accurate to ±1% of tank capacity.

ATEX certified – probe rated for Zone 0 & 1
Accuracy ±1% of tank capacity
4–20 mA output to building management systems
Petrol, diesel, kerosene, B100 & AdBlue®

Request a Quote Talk to an Engineer

Description

OLE Z2000 ATEX Tank Gauge – ±1% Accuracy

Monitor tank contents continuously with the OLE Z2000 ATEX-certified tank gauge. Based on the OLE C2020, it displays volume in litres and percentage with ±1% accuracy of tank capacity.

Suitable for petrol, kerosene, diesel, biodiesel up to B100, AdBlue® and antifreeze, the standard kit covers tanks from 0.3 m to 3 m high, or up to 2.75 m for AdBlue®.

Key features and benefits

ATEX-certified pressure probes rated for Zones 0 and 1
Continuous digital readout in litres and percentage
IP65 weatherproof housing
Backlit display with a one-hour timeout
Choice of 230V, 110V or 24V DC power supply
4–20 mA output for connection to a building management system
High- and low-level alarms with a 110 dB sounder on the Z2000-A-ATEX-A12 kit
Front-panel setup or calibration service within 24 hours of receiving a completed tank questionnaire

Installation and accessories

The pressure probe has a 1-inch BSPT male fitting and must be suspended 50 mm above the tank bottom. One gauge is required per tank. Probe cables can be extended up to 100 m using the specified CABLE-4CV low-loss vented cable and T4020-EJ ATEX junction box.

Stock code	Description
Z2000-A-ATEX-A12	Tank gauge kit with high/low alarms and 10 m cable
B8-ATEX	ATEX level switch or bund probe with barrier kit
B2-ATEX	ATEX water-bottom sensor; requires at least 15 mm of water
T4020-OJ	Sealing probe adaptor for a 30 mm tank opening
T4020-EJ	Zone 1 and 2 ATEX junction box for cable extensions
CALIB-Z2000	Calibration using customer-supplied tank dimensions

Other gauge kits with sensor ranges up to 30 m are available.
